Schlage FE-Series Electronic Locksets

FE/BE-Series Keypad Locks Specifications

Professional Grade Security and Quality:

• Grade 2 ANSI/BHMA certified
• Patented commercial grade clutching motor drive; tested to one million cycles
• Vandal resistant clutching lever and knob design; free spinning deadbolt turn
• Code control; 6-digit programming code required to add and delete user codes
• Warning code sounds after four incorrect codes entered; keypad disabled for 30 seconds
• Mechanical key override; patent pending

Convenience:

• Convenient keyless access; no keys to hide, lose or forget
• Pre-set with random 6-digit programming code and two random 4-digit user codes
• 19 user code capacity; 10,000 user code combinations
• Easily programmed right at the keypad; no need to remove inside escutcheon
• Blue LEDs illuminate the keypad on demand
• Reversible levers for left- or right-handed doors
• Emergency exit feature; allows for panic-free exit on FE575 and FE595
• Locks can be re-keyed to match existing locks
• 9-volt alkaline battery included
• Up to 3 year battery life with low battery alert

FE285/BE365 Keypad Deadbolt and Handleset with Lever

• Applications: Residential single- and multi-family doors
• Certifications: Grade 2 ANSI/BHMA certified
• Keying: 5-pin tumbler C keyway with two nickel silver keys
• Door range: 1-3/8” to 1-3/4” (35mm-44mm) standard; thick door kit available on BE365
• Backset: Universal latches and deadbolts fit 2-3/8” (60mm) or 2-3/4” (70mm) backset
• Innovative Turn-Lock feature allows you to lock & leave without a key
• Provides the convenience of keyless access; customizable to fit your security needs
• Ideal for front doors, side & back doors, garage entry doors, etc.
• Easily replace most exisiting deadbolts with a screwdriver in about 30 minutes
• No programming required; preset with two user codes so it's ready to use right out of the box
• Fits standard door prep
• Easy installation, no need to run wires
• Battery operated with over 3 year battery life

FE285/BE369NX Connected Keypad Deadbolt (Z-Wave) and Handleset with Lever

• Applications: Residential single- and multi-family doors
• Certifications: Grade 2 ANSI/BHMA certified
• Keying: 5-pin tumbler C keyway with two nickel silver keys
• Door range: 1-3/8” to 1-3/4” (35mm-44mm) standard; thick door kit available on BE365
• Backset: Universal latches and deadbolts fit 2-3/8” (60mm) or 2-3/4” (70mm) backset
• Communications: 900 MHz (Z-Wave ® RF)
• Innovative Turn-Lock feature allows you to lock & leave without a key
• Provides the convenience of keyless access; customizable to fit your security needs
• Ideal for front doors, side & back doors, garage entry doors, etc.
• Easily replace most exisiting deadbolts with a screwdriver in about 30 minutes
• No programming required; preset with two user codes so it's ready to use right out of the box
• Fits standard door prep
• Easy installation, no need to run wires
• Battery operated with over 3 year battery life

FE595 Keypad Lever with Flex-Lock

Switch between unlocked or automatic re-locking

• Personalized four-digit codes grant access to the home
• No wiring required – installs in minutes
• Wear-resistant, silicone-coated keypad prevents numbers from wearing off
• Backlit, simple keypad is easy to see and use
• Biggest bolt available for increased resistance to kick-ins
• Innovative turn-lock feature allows you to lock and leave without a key
• Electronic door locks are not just ideal for your home’s front door – add to any side door, back door, garage entry, interior rooms and offices, and even wine cellars

FE599NX Connected (Z-Wave) Keypad Lock

• Grade 2 ANSI/BHMA-certified
• Epoxy coated buttons to prevent fading and wear
• Wireless installation in just minutes
• Guaranteed to fit existing pre-drilled standard doors
• Limited lifetime mechanical and finish warranty; 1 year electronics warranty
• Employs Z-Wave®, a wireless technology that makes your house smarter, safer and far more convenient
• Holds up to 19 user codes
